AXISCameraStationS22ApplianceSeries
Managethebuilt-inswitch
Note
YoucanalsoturnonandturnoffPoEinthePowermanagementpage.
Lockandunlockports
YoucanlockaMACaddresstoaportsothatonlytrafccomingfromthatMACaddresswillpass.Thisimprovessecurityandprevents
unauthorizedusersfromconnectingalaptoporotherdevicestothesecuritynetwork.
Lockaport
1.Intheswitch’smanagementpage,clickOverview.
2.IntheLockcolumn,click
tolocktheport.
Lockallports
1.Intheswitch’smanagementpage,clickOverview.
2.Click
andselectLockallports.
Unlockaport
1.Intheswitch’smanagementpage,clickOverview.
2.IntheLockcolumn,click
tounlocktheport.
Unlockallports
1.Intheswitch’smanagementpage,clickOverview.
2.Click
andselectUnlockallports.
Powermanagement
Intheswitch’smanagementpage,clickPowermanagement.
Generalinformation
•PortsusingPoE:thenumberofportswithPoEenabledthatareinuse.
•CurrentPoEusage:thePoEpowerinwattsconsumedbydevicesandthepercentageofusedPoEpoweroutofthe
totaldedicatedPoEpower.
•Powerrequested:thetotalpowerinwattsandpercentageallocatedtodevices.OnlyavailablewhenyouselectReserved
powerasthepowerallocationmethod.
Portlist
ItemDescription
PortTheportnumberthatthedeviceisconnectedto.
PoEThePoEstatus.YoucanclicktheicontoturnonorturnoffPoEontheport.
PoEclassThePoEclassoftheconnecteddevice.
PriorityThepriorityofpowerallocationtotheconnecteddevice.Lowernumberedportshavehigherpriority.
Bydefault,thepriorityistheportnumber.
Powerconsumption(W)
Thepowerinwattsconsumedbythedeviceconnectedtotheport.
33
