Axis V5914 - Hardware Overview; Connectors and Buttons

AXISV5914PTZNetworkCamera
HardwareOverview
HardwareOverview
1 2 3 4
5
6
7
8 9
1
Powerconnector
2
3.5mm,unbalancedaudioin
3
3.5mm,unbalancedaudioout
4
Networkconnector
5
MicrophonepowerLED(XLR)
6
XLR,balancedaudioin(left)
7
XLR,balancedaudioin(right)
8
BNCconnector(SDI)
9
HDMIconnector
10 11 12 13 14
10
SDcardslot(SDHC)
11
StatusLEDindicator
12
I/Oconnector
13
Controlbutton
14
TallyLED(3x)
ConnectorsandButtons
Fortechnicalspecications,seepage58.
BNCConnector
TheBNCconnectorisusedforconnectingbroadcastequipmentusingSDI.Connecta75OhmcoaxialSDIcable.
CAUTION
Theconnectormaybehotduringnormaloperationinelevatedambienttemperatures.
