Axminster AWESBS - Illustration and Parts Description

16
WHITE
AXMINSTER
W
Illustration and Parts Description...
Main saw frame
Upper blade
guide and
guard
Fence guide rail
Mitre fence
Saw table insert
Floor cabinet
Dust extraction outlet
On/Off button and
switch shroud
On/Off buttons
Switch shroud
Upper saw wheel
(inside cover door see fig 8)
Blade tensioning wheel
Upper cover door
Lower cover door
Lower cover door latch
Lower cover
door latch
Upper blade guide
height clamp
Upper cover door latches
Idler wheel
adjusting knob
Lock lever
Guide fence
Fig 6
Fig 6a
