What’s Included
3
Please read the Instruction Manual prior to using your new machine; as well as the operating procedures for your new
machine, there are numerous hints and tips to help you to use the machine safely and to maintain its efficiency and prolong its
life. Keep this Instruction Manual readily accessible for any others who may also be required to use the machine.
1
Quantity Item Model Number
AT3086B
1 Trade Bandsaw
1 Blade 3,086.1mm (121.5”) long, mounted on saw but not tensioned.
1 Cast Iron Table 1
Fence Assembly: Bags Comprising:
1 Front Fence Rail with Scale 2 1 Mitre Fence Assembly 12
1 Fence 3 a) Threaded lever with washer
1 Fence Clamp Assembly with b) Two Grub screws
Magnifying Glass 4 c) Two Hex Keys 3-4mm
1 M8 Threaded Lever 5 d) Mitre Fence Body
1 M8 Lift and Shift Handle 6 e) Threaded ‘T’ bolts with Clamping Knobs
1 Threaded ‘T’ Slot Insert 7 f) Aluminium Fence
2 M6 x 20mm Threaded Bolts 8 g) Depth Stop Assembly
1 M8 Large Washer 9
2 M6 Small Washers 10 1 Table Alignment Pin Handle 13
1 M8 Nut 11 1 10-13mm Spanner 14
1 4-5-8mm Hex Keys 15
4 M8 Washers 16
4 M8 Spring Washers 17
4 M8 x 16mm Threaded Bolts 18
1 Fence Assembly Support bracket 19
1 User Manual 2 M6 Cap head screws with washers 20
1 Large Washer and Nut
(for Table Alignment Pin Handle) 21
HAVING UNPACKED YOUR ACCESSORIES PLEASE
DISPOSE OF ANY UNWANTED PACKAGING
PROPERLY. THE POLYTHENE AND CARD ARE
RECYCLABLE.
To Next Page
