Maintenance
32
Daily
Weekly
• Keep the machine clean.
• Check the saw blade for missing teeth and cracks, see fig 97.
• Spray Axcaliber Dry lubricant on the bare metal surfaces.
• Open the top and bottom wheel covers and clean out all
saw dust and impacted ‘crud’ from the wheels and
compartment area, see 98-99-100.
• Check the condition of the upper/lower blade guides and
thrust bearings and clean any impacted ‘crud’ from the
bearings using a soft brush, eg. paint brush then spray dry
lubricant, (Axcaliber Dy Lubricant) on the bearings to prevent
resin build up , see fig 101-102.
Fig 97
Fig 98
Fig 99-100
Clean out impacted ‘crud’ and saw dust
Fig 101-102
Check for missing
teeth and cracks in
the blade
DISCONNECT THE SAW FROM THE
MAINS SUPPLY!
To Next Page
