Axxess ASWC User Manual

axxessinterface.com 800.221.0932
10)After4secondsoftheledashingquicklytheledwillgooutfor2seconds.
11)Thentheledwillash,upto9times,dependingonwhatradiotheASWCthinksit’sconnectedto.
Here are the led blinks and which radio they represent:
1stledashisforEclipse
2ndledashisforKenwood
3rdledashisforClarion
4thledashisforSonyandDual
5thledashisforJVC
6thledashisforPioneerandJensen
7thledashisforAlpine*
8thledashisforVisteon
9thledashisforValor
*Note:IftheASWCashes7timesandyoudonothaveanAlpineradioconnectedtoitthatmeans
that the ASWC did not see any radio connected. Verify the 3.5mm connector is connected to the
SWC input on the radio.
12)Makesurethenumberofashesmatchwhatradioyouhaveinstalled.
13)IftheledashesmatchtheradiothenholddowntheVolumeDownbuttonuntiltheledgoessolid
red.
14) Programming for the vehicle and the radio is now complete. Test out the steering wheel control
functions to make sure it works correctly.
Iftheledashesdonotmatchtheradioyouhaveconnected,youmustmanuallyprogramtheASWC
to tell it what radio it is connected to.
1) To manually program the aftermarket radio, press and hold the Volume Up button on the steering
wheel control until the led goes solid red, then release Volume Up.
2) At this point Eclipse is programmed.
If you are using an Eclipse radio go to step 3.
If you are using a different radio go to step 4.
3)PressandholdVolumeDownfor5seconds.Theledwillashoncethengosolidredindicatingthe
programminghasnished.Goenjoyyourradio.

Axxess ASWC Specifications

General

Type	Steering Wheel Control Interface
Updateable	Yes
Programming	Automatic or manual programming options
Installation	Plug-and-play installation with vehicle-specific harness
Functionality	Retains steering wheel control functions
Vehicle Coverage	Covers a wide range of vehicles
Connector Type	Vehicle-specific wiring harness
Firmware Updates	Yes
