Axxess ASWC User Manual

axxessinterface.com 800.221.0932
4) If you have a different radio then Eclipse, press the Volume Up button again till the led goes solid
red, then release Volume Up. You have now programmed Kenwood.
5) Here is the chart to show how many presses of the Volume Up button is needed for which radio
you are trying to program:
1stledashisforEclipse
2ndledashisforKenwood
3rdledashisforClarion
4thledashisforSonyandDual
5thledashisforJVC
6thledashisforPioneerandJensen
7thledashisforAlpine*
8thledashisforVisteon
9thledashisforValor
*Note:IftheASWCashes7timesandyoudonothaveanAlpineradioconnectedtoitthatmeans
that the ASWC did not see any radio connected. Verify the 3.5mm connector is connected to the
SWC input on the radio.
6) Once the radio manufacturer has been selected hold Volume Down for at least 5 seconds. The
ledwillashthenumberoftimeswhichradiowasselectedthentheledwillremainontoindicate
theASCWhasnishedprogramming.
7) Go enjoy your radio.
Remapping the SWC Buttons
Let’s say you have the ASWC programmed to your vehicle and your radio and you want to change
the button assignment for the steering wheel controls. For instance you would like Seek Up to be
Mute.
This process is the same as manually programming the ASWC (please refer to the Manual Program-
ming section) with a couple of notes:
•TheASWCmusthavedetectedthevehicleandradioitisattachedtobeforeyoucanremap
any buttons.
•Youcanonlystarttheremappingofthesteeringwheelcontrolsprocesswithintherst20seconds
of turning the ignition key on. If you wait longer then the 20 seconds you will have to turn the
ignition off then back on again.
•Withintherst20secondsifanybuttonotherthenVolumeUporVolumeDownispushed,the
remapping process will stop.
•Ifduringtheremappingprocessnobuttonispushedfor30secondstheremappingprocessis
aborted and the original settings are reset.

Axxess ASWC Specifications

General

Type	Steering Wheel Control Interface
Updateable	Yes
Programming	Automatic or manual programming options
Installation	Plug-and-play installation with vehicle-specific harness
Functionality	Retains steering wheel control functions
Vehicle Coverage	Covers a wide range of vehicles
Connector Type	Vehicle-specific wiring harness
Firmware Updates	Yes
