Axxess CHTO-03 User Manual

2
CONNECTIONS TO BE MADEAPPLICATIONS
From the 16-pin harness
• Connect the (2) Red wires to the ignition/accessory wire of the aftermarket radio.
• Connect the Orange/White wire to the illumination wire of the aftermarket radio. If the
aftermarket radio does not have an illumination wire, tape off the Orange/White wire.
• Connect the Blue/White wire to the amp turn on wire of the aftermarket radio.
• Tape up the Brown wire. It will not be used in this application.
For vehicles with built-in navigation (only), make the following connections:
• Connect the Light Green wire to the parking brake wire of the aftermarket navigation radio.
• Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket navigation radio .
• Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio.
Only make the following connections if the vehicle is amplified:
• Connect the White wire to the left front positive speaker output of the aftermarket radio.
• Connect the White/Black wire to the left front negative speaker output of the aftermarket radio .
• Connect the Gray wire to the right front positive speaker output of the aftermarket radio.
• Connect the Gray/Black wire to the right front negative speaker output of the aftermarket radio .
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker output.
• Connect the Purple wire to the radio’s right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative speaker output.
Continued on next page
CHRYSLER
200 2011-up
300 2008-2010
Aspen 2008-2009
Sebring 2007-2010
Town and Country 2008-up
DODGE
Avenger 2008-up
Caliber 2009-2012
Challenger 2009-up
Charger 2008-2010
Dakota 2008-2011
Durango 2008-2013
Grand Caravan 2008-up
Journey 2009-2010
Magnum 2008-2009
Nitro 2007-2011
Ram 1500 2009
Ram 2500/3500 2010-2011
JEEP
Commander 2008-2010
Compass 2009-up
Grand Cherokee 2008-2013
Liberty 2008-2012
Patriot 2009-up
Wrangler 2007-up
MITSUBISHI
Raider 2008-2009
Ram
1500/2500/3500 2012
C/V Tradesman 2012-up
Chassis Cab 3500/4500/5500 2012
