XSVI-6523-NAV
2
Connections to be made
From the XSVI-6523-NAV harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Red wire to the accessory wire.
Note: If installing an ASWC-1 (sold separately), there will be an accessory wire there
to connect as well.
•
For the Fiat 500L only: Connect the Blue/White wire labeled “500L amp turn on” to the
amp turn on wire. This wire must be connected to hear sound from the factory amplifier
.
• For all models except the Fiat 500L: Connect the Blue/White wire to the amp turn
on wire. This wire must be connected to hear sound from the factory amplifier.
• If the aftermarket radio has an illumination wire, connect the Orange wire to it.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
• Connect the Green wire to the left rear positive speaker output.
• Connect the Green/Black wire to the left rear negative speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the right rear negative speaker output.
The following (3) wires are only for multimedia/navigation radios that require these wires.
• Connect the Blue/Pink wire to the VSS/speed sense wire.
• Connect the Green/Purple wire to the reverse wire.
• Connect the Light Green wire to the parking brake wire.
• If retaining the factory backup camera, connect the Yellow RCA jack to the backup
camera input.
• If retaining the factory AUX-IN jack, connect the Red & White RCA jacks to the AUX input.
12-pin pre-wired ASWC-1 harness:
• This harness is to be used along with the optional ASWC-1 (not included) to
retain steering wheel audio controls. If the ASWC-1 is not being used, disregard
this harness. If it will be used, please refer to the ASWC-1 instructions for radio
connections and programming.
Note: Disregard the harness that comes with the ASWC-1.
• Connect the Red wire to the accessory wire.
