CONTROL PANEL
Stand-by button
Timer button
Sleep button
Dehumidifying button
Speed button
Mode button
Automatic, Cool, Fan mode
Timer/Temperature up button
Timer/Temperature down button
Low, middle high fan speed
OPERATION
Turn on the unit
1. Plug in, then the unit beeps once.
2. Press the button, then the unit is turned on.
3. The LED displays the room temperature and operates in Automatic
mode.
Select operating mode
Press the button to select a desired mode shown below:
Adjust Temperature
• The temperature can be set within a range of 15°C to 31°C by 1°C
• Press or button to increase or decrease the temperature 1°C by
pressing once.
• The unit LED shows the target temperature for 5 se
conds and then
displays the room temperature.
Adjust Fan Speed
Press the button to select a desired fan speed shown below:
Standby
After pressing the button again, the unit will emit a “di” and stop
working.
Automatic mode
• Once the Operation is selected, the indoor temperature sensor
operates automatically to select the desired operation mode with
or
• When the room temperature
≥
24°C ,the unit will automatically
select mode.
• When the room temperatu
re
<
24°C,the unit will automatically
select mode .
Dehumidify mode
• The up centrifugal fan will run at low speed, and the speed can’t be
adjusted.
• The compressor and the down centrifugal fan will stop after
running 8 mins, then run again after 6 mins .
• The unit adopts constant temperature dehumidifying mode ,and
the adjustment of temperature is no effective.
Cooling mode
• When the room temperature is higher than set temperature, the
compressor starts to run.
Power
Dehumidifying
Timer
Mode
Sleeping
Speed
