Ayra ComPar KIT 3 - Device Overview; Main Fixture and Controller Components; Spotlight Components

Device overview
Main fixture
1. Electronic mounting bar
2. Spotlight
3. Stand adapter (35mm)
Foot controller
4. Menu button
5. UP button
6. Suspend button (blackout)
7. Connection cable with locking connector
Mounting feet
7. Metal bracket
8. Rubber foot
9. Screw set for mounting feet (included)
Spotlight
10. Housing
11. Reflector
12. Removable lens
Any information and illustrations shown in this user manual are subject to change without further notice.
User manual version: 1.0 Creation date + author initials: 22-04-2015 RV Revision date + author initials: -
