Chapter 1 Precautions
Fig. 1-3. Structure of probe and peripheral parts
Table 1-2. Main materials of probe and peripheral parts
Part Main material Weight of main material
Cable-retaining flange Stainless steel SUS F304 Approx. 2,000 g (for JIS 10K 50A)
Hollow cable Polyethylene -- Approx. 260 g/m
Housing with cover Stainless steel SUS 304 Approx. 1,060 g
Weight Stainless steel SUS 304 Approx. 6,000 g (for Φ300)
Chain Stainless steel SUS 304 Approx. 530 g/m
Housing (probe)
Cable-retaining flange
Electronics module
Hollow cable
Meterbody
Cover (lower portion)
Cover (upper portion)
Chain
Shell
Weight
