9-4
Chapter 9 Maintenance and Inspection
(3) Disconnect the connector from the printed circuit board inside the probe. When
disconnecting the connector, be sure to hold the connector body. Pulling the lead wires
may cause wire(s) to break.
Fig. 9-4. Disconnecting the connector
y
Removing the Meterbody and Housing
(1) Turn the lower cover of the probe to remove it.
Lower cover
Fig. 9-5. Removing the lower cover
Connector
To Next Page
