3 AB-6650
CAUTION (2/2)
• Position the cable connected between the controller and the 4-elecrode sensor away from heavy-current
wiring and circuit to avoid induction current.
• Controller power needs to be supplied from the single-phase power source for noise reduction. If the
controller receives noise from the power supply line, provide isolating transformer and line filter.
• Do not position the cable connected between the controller and the 4-elecrode sensor or the wires for PV
output close to the inverter.
• Do not incinerate the controller or the 4-electrode sensor for waste disposal (the housings produce toxic gas
when incinerated). Do not recycle all or part of them, either.
• Dispose of the controller and the 4-electrode sensor in accordance with local regulations.
Trademark information:
MIZCON is a registered trademark of Azbil Corporation in Japan.
Model Numbers
Controller (main unit)
Base model
number
Fixed Temperature
PV*
1
output
Fixed Temperature
control output
Description
R7010W MIZCON Plus
- Control output of blowdown valve for cooling water:
potential free N.O./N.C.*
2
contact
- Conductivity PV output: 4-20 mA DC
- Alarm output: potential free N.O. contact
(for sensor error or conductivity over the high limit)
- Interlock input: potential free contact
1 ⎯
0 No temperature PV output
4 Cooling water temperature PV output: 4-20 mA DC
0 ⎯
0 No temperature control output
1 Temperature control output: potential free N.O. or N.C. contact × 1 pt.
2 Temperature control output: potential free N.O. or N.C. contact × 2 pts.
Notes:
∗1 PV: Process Value
∗2 N.O: Normally Open / N.C: Normally Closed
4-electrode sensor
Separate order is required for the sensor. Be sure to select your applicable sensor and order by its part number.
Part number Description
81301430-001 Immersion type 4-electrode sensor:
For Model R7010W (MIZCON Plus) / R7010B (MIZCON), with temperature sensing, with 4 m long cable
81301430-002 Immersion type 4-electrode sensor:
For Model R7010W (MIZCON Plus) / R7010B (MIZCON), with temperature sensing, with 20 m long cable
