EN-14
8.InstalltheRearCamera(IP68waterproof)outsidethecar.
Plugtherearcameracableintothe
MiniUSBinputsocketoffrontcamera.
InstallRearCamera
Herearethreeexamplesofwheretoguiderearcamera'swire.
8.1.Selectaflatandcentralplacethatnearthenumberplatelampatthe
rearofthevehicletomountcamera.
8.2.Attachtapetothebracketofthecameratoholdthecamerainposition
whileinstalling,anddrilltwosmallholes,oneforthefirstscrew,thesecond
torunthereversecameracablethrough.
