12
User Manual v1.4.3
HYDRODIGIT
Telegram reading (direction: meter other)
Code
Field
No.
Bytes
Value
(hex)
Total
Length
Description Notes
AES verify 2 2F 2F If AES is enabled
Dif 1 0C Data Information Field: indicates the format
of the read (8 BCD digits)
Vif 1 13/14/15/16 Value Information Field: indicates the unit
of measurement (13-liter, 14-decaliters,
15-hectoliters, 16-m3)
Data 4 xx xx xx xx Instant counter value
Dif 1 04 Date and time
Vif 1 6d Date and time – Type F
Data 4
xx xx xx xx xx
Data and hour value
Dif 1 0F Data Information Field: start of manifacture
specic data
Optional
MS Code 1 xx Bit encoding of subsequent elds:
bit0: if set, the battery voltage eld is present
bit1: if set, the reverse stream eld is
present
bit2: if set, fraud date is present
bit3: if set, the date in which the water
leakage was detected or has been nished
is present
bit4: if set, the date in which the burst was
detected is present
bit5: if set, value at memory day 1 is present
bit6: if set, value at memory day 2 is present
bit7: if set, the historic is present
Fraud date 3 dd mm yy Day month year of the rst fraud detected
(00 00 00 if it did not happen).
In the H nibble of the month there is the type
of fraud:
bit 7: -
bit 6: Reverse stream
bit 5: overow
Optional
Water loss
date
3 dd mm yy Day month year in which it was detected
that
there is a water leak (00 00 00 if it did not
happen)
Optional
Date burst 3 dd mm yy Day month year when it was detected that
there is burst (00 00 00 if it did not happen)
Optional
