B meters HYDRODIGIT User Manual

23
User Manual v1.4.3
HYDRODIGIT
HEADER property Data
Fct C/R/A Err Chain Len
Device
type
Day
Week
day
Month Year Hour Minutes Seconds
1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte
0x15 1 0 0 0x08 0x05 1 1 1 18 10 23 0
Answer:
The Date eld is described as follows (BCD format):
Name Type Default Minimum Maximum Index
Day Uint8_t 1 1 31 1
Day of the week
(0: Sunday, 1: Monday..)
Uint8_t 0 0 6 2
Month
(1: January, 2: February..)
Uint8_t 1 1 12 3
Year Uint8_t 18 18 100 4
Hour Uint8_t 0 0 23 5
Minutes Uint8_t 0 0 59 6
Seconds Uint8_t 0 0 59 7
The Err eld can have the following meanings:
0x00 – No error
0x01 – Error data eld not valid.
0x02 – Error on the device type
0x04 – Error on the command length.
SET_TX_PAR (0x24)
This command sets the meter to 2 or 4 transmissions per day in LoRaWAN mode.
From Application server to meter:
HEADER property Dati
Fct C/R/A Err Chain Len Device type
Interval
between tx
1 byte 1 byte 1 byte 1 byte 1 byte 1 byte 2 byte
0x24 0x00 0x00 0x00 0x03 0x05 0x5460
Answer:
HEADER property Data
Fct C/R/A Err Chain Len Device type
1 byte 1 byte 1 byte 1 byte 1 byte 1 byte
0x24 0x01 0x00 0x00 0x01 0x05
