3
User Manual v1.4.3
HYDRODIGIT
Size
mm
in
15
(1/2”)
15
(1/2”)
20
(3/4”)
L mm 80 110 130
B mm 85 85 85
I mm 160 190 228
D Threading in 3/4” 3/4” 1”
H mm 73 73 73
h mm 18 18 18
L
I
B
H
D
h
CONTENT
DESIGN
According ISO4064
