Telegram reading (direction: meter  other)
Code
Field
No.
Bytes
Value
(hex)
Total
Length
Description Notes
Data 3
xx xx xx xx
November-relative reading (HEX, decalitres if
VIF is 13, hectolitres if VIF is 14, m3 if VIF-15,
10xm3 if VIF-16)
Optional
Data 3
xx xx xx xx
December-relative reading (HEX, decalitres if
VIF is 13, hectolitres if VIF is 14, m3 if VIF-15,
10xm3 if VIF-16)
Optional
Data 1 xx Reading Acquisition Day (1-28 BCD) with note
at 0.00. Value 0 indicates the last day of the
month with note at h23.59.
Optional
AES ll N 2F (-n) If AES is enabled cript
Wireless MBUS OMS v4 (COMBO, output conguration Wireless MBUS OMS v4 only)
This section describes the management of the communication standard Wireless MBUS OMS v4.
Code eld No.
bytes
Value
(hex)
Total
Length
Description
Header 2 AA36 2 Header
L eld 1 xx 3 Message lenght
C eld 1 44 4 Control eld. Shows the direction.
M eld 2 B409 5 Manufacturer code: BMT
A eld 4 xxxxxxxx 8 8-digit serial number of the device
Generation 1 17 12 WMBUS generation
Medium 1 07/06 13 Medium (water/hot water)
ELL data 1 8C 14 ELL header
ELL data 1 00 15 CC eld
ELL data 1 xx 16 ACC eld
CI eld 1 7A 17 Control info: shows the next data code
Frame counter 1 xx 18 Progressive count of the frame
