Air Inlet Louvres
Air inlet louvres are a lift and drop in design. They are to be installed
with utes facing downwards into basin. A shorter louvre is provided to t
over the quick ll/makeup.
Float Valve
If the unit has shipped without the oat arm/ball assembly attached this
should be installed as per Figure 7, before louvres are installed.
Figure 7. Attaching oat arm
