BAC RC Series Rigging & Assembly Instructions

W W W . B A L T I M O R E A I R C O I L . C O M . A U
2
M A R 2 0 8 - 0
1
RC SERIES
Introduction
Safety
Adequate precautions appropriate for the installation and location
of these products should be taken to safeguard the equipment and
the premises from damage and the public from possible injury. The
procedures listed in this manual must be thoroughly reviewed prior to
rigging and assembly. Read all warnings, cautions, and notes detailed
in the margins.
When the fan speed of the unit is to be changed from the factory set
speed, including the use of a variable speed device, steps must be
taken to avoid operating at or near the fan’s “critical speed” which
could result in fan failure and possible injury or damage. Consult with
your local BAC Representative on any such applications.
Shipping
BAC RC Series units are factory assembled to ensure uniform quality
with minimum eld assembly. As standard, models ship in two sections
per cell (lower and upper). Optional shipment of three sections per
cell and optional containerized shipments are available. Contact your
local BAC Representative for more information. For the dimensions and
weights of a specic unit or section, refer to the submittal drawings.
Pre-Rigging Checks
When the unit is delivered to the jobsite, it should be checked
thoroughly to ensure all required items have been received and are free
of any shipping damage prior to signing the bill of lading.
The following parts should be inspected:
WARNING: Failure to use
designated lifting points
can result in a dropped load
causing severe injury, death,
and/or property damage.
Lifts must be performed by
qualied riggers following BAC
published Rigging Instructions
and generally accepted
lifting practices. The use of
supplemental safety slings
may also be required if the
lift circumstances warrant
its use, as determined by the
rigging contractor.
WARNING: This equipment has
the potential to be a high risk
hazard! Do not handle, rig,
lift, install, assemble, operate,
maintain or enter this
equipment without assessing
the risks involved. control
measures must be developed
to eliminate or minimise the
potential risks.
 Sheaves and Belts
 Bearings
 Bearing Supports
 Fan Motor(s)
 Fan Guard(s)
 Fan(s) and Fan Shaft(s)
 Float Valve Assembly(s)
 Fill
 Water Distribution System
 Cold Water Basin Accessories
 Interior Surfaces
 Exterior Surfaces
 Louvres
 Mating Surfaces Between
Sections/Modules
 Miscellaneous Items:
All bolts, nuts, washers,
and sealer tape required
to assemble sections
or component parts are
furnished by BAC and
shipped with the unit.
A checklist inside the
envelope marked “Customer
Information Packet”
indicates what miscellaneous
parts are included with the
shipment and where they are
packed. This envelope will
be attached to the side of
the unit or located in a box
inside the unit.

BAC RC Series Specifications

General

Brand	BAC
Model	RC Series
Category	Chiller
Language	English
