Section 2. Mounting Instructions
2.1. Installation Warnings
WARNING: Explosion hazard! Do not mount the MGS
Controller in an area that may contain flammable liquids,
vapors, or aerosols. Operation of any electrical equipment in
such an environment constitutes a safety hazard.
CAUTION: The MGS Controller contains sensitive electronic
components that can be easily damaged. Do not touch nor
disturb any of these components.
NOTE: The mounting location of the MGS Controller should
allow it to be easily accessible for visual monitoring and
servicing.
NOTE: The MGS Controller must be connected by a marked,
suitably located and easily reached switch or circuit-breaker
as means of disconnection.
NOTE: Connect power and signaling terminals using wiring
that complies with local electrical codes or regulations for the
intended application.
CAUTION: The MGS controller contains sensitive electronic
components that can be easily damaged. Do not touch nor
disturb any of these components
2.2. Location Recommendations
NOTE: The MGS Controller should be installed plumb and
level and securely fastened to a rigid mounting surface.
At a minimum, the MGS Controller must be located within the
appropriate wire lengths from the sensors being monitored. In addition,
consider environmental conditions and accessibility. Refer to Section 3
for more information on sensor wiring lengths.

Bacharach MGS SERIES Specifications

General

Power Supply	24 VDC
Operating Temperature	-20°C to 50°C
Communication	Modbus RTU
Output	4-20 mA
Enclosure Rating	NEMA 4X
