Bacharach MGS SERIES User Manual

MGS Series Controller Manual
20 6709-9000 Rev 1
3.3. External Horn (for Audible Alarms)
Horn Specifications (Test Conditions at 25
°
C)
Specification Description
Housing Black ABS
Power Rating 10 W (RMS), 15 W (peak)
Voltage 12 VDC (Rated), 6-16 VDC range
Current 200 mA max (@ 12 VDC)
Sound Pressure Level Minimum 100 dB at 1 meter (@ 12 VDC)
Connections Red: +12 V, Black: Ground
Weight
2.3 ± 0.2 oz (65 ± 5 g)

Bacharach MGS SERIES Specifications

General

Power Supply	24 VDC
Operating Temperature	-20°C to 50°C
Communication	Modbus RTU
Output	4-20 mA
Enclosure Rating	NEMA 4X
