Backyard Creations 01471 - Package and Hardware Contents; Package Contents; Hardware Contents; Tools Required

4
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
Handle 2
Lid 1
Lid Hanger 3
Screens/Screen Doors 3/1
Door Latch 1
Grate 1
Bowl 1
Air Vent 1
Leg Stand 2
Axle 1
U-Leg 1
Wheels 2
HARDWARE CONTENTS
q
w
e
r
t
y
u
i
o
1)
1!
1@
al
am
am
1
7
8
9
5
1
2
3
4
6
M6x15
Screw/Nut
Qty: 28
M6x18
Washer
Qty: 34
M6x9 lock
Washer
Qty: 34
A
D
M5x10
Screw/lock Nut
Qty: 1
C
B
M12x22
Washer
Qty: 2
M10 lock Nut
Qty: 2
Connecting
bracket
Qty: 8
(Not in blister pack)
M6x35
Screw/Nut
Qty: 6
E
F G
I
M5x10
Screw/Nut
Qty: 1
H
TOOLS REQUIRED
(Not included)
• Adjustable Wrench
(or 1
7mm, 10mm, and 8mm wrenches)
• Pliers
• Phillips-head Screwdriver

Contact us for assistance: cservice@welltraveled.net
