8
Figure 4
4. With the help of another person, carefully place the table top onto the firepit base. After
making any necessary adjustments to the alignment of the table top and the assembled
base, use four 1/4"x20 mm bolts and Ø20xØ6.5x2.0 mm washers as shown in Figure 5.
Guide the bolts through the holes in the base brackets, into the predrilled holes in the table
top. Do not tighten completely.
Figure 5
5. Attach the LP support to the lp support frame by using a 1/4"x15 mm bolt and washer as
shown in Figure 6. Do not overtighten.
Figure 6
