Backyard Discovery BEACH FRONT - Page 11

Parts Identification
Wood Components
(NOT TO SCALE)
Y3 - SUNBURST HALF MOON - W4L06954
5/8"x4"x12" (16x102x306)
(2)
N3 - SUNBURST BOARD - W4L06955
5/8"x2 3/8"x11 3/4" (16x60x299)
(2)
N4 - SUNBURST BOARD - W4L06956
5
/8"x2 3/8"x8 1/8" (16x60x205)
(4)
O4 - AWNING BOARD - W4L06957
5/8"x1 3/8"x32 1/4" (16x34x818)
(1)
SB74 - SWING BEAM EXTENDED - W4L06961
2"x5 1/4"x89 1/2" (50x134x2274)
(1)
E77 - ANGLE BRACE - W4L06962
1 3/8"x3 3/8"x74 3/8" (36x86x1890)
(2)
W71 - SWING BEAM SUPPORT - W4L06963
2"x3 3/8"x49 5/8" (50x86x1260)
(1)
E5 - MONKEY BAR UPRIGHT - W4L06964
1
3/8"x3 3/8"x70 3/8" (36x86x1786)
(2)
H81 - MONKEY BAR BRACE - W4L06965
1"x3 3/8"x19 3/8" (24x86x492)
(2)
M82 - MONKEY BAR GROUND BOARD - W4L06966
5/8"x3 3/8"x40 3/8" (16x86x1026)
(1)
H7 - BENCH GROUND BOARD - W4L06967
1"x3 3/8"x18 1/8" (24x86x460)
(2)
H8 - BENCH UPRIGHT - W4L06968
1"x3 3/8"x11 3/4" (24x86x300)
(2)
H9 - BENCH SEAT SUPPORT - W4L06969
1"x3 3/8"x6 1/2" (24x86x166)
(2)
M12 - BENCH SEAT - W4L06970
5
/8"x3 3/8"x26" (16x86x660)
(2)
E7 - MONKEY BAR RAIL - W4L06938
1 3/8"x3 3/8"x48" (36x86x1219)
(2)
H79 - END SUPPORT - W4L06923
1"x3 1/2"x42" (24x86x1072)
(1)
