Backyard Discovery BEACH FRONT - Page 48

STEP 17
O4
O4 - AWNING BOARD - W4L06957
5
/8"x1 3/8"x32 1/4" (16x34x818)
(1)
- AWNING - A6P00124
1/64"x32 1/4"x22 1/4" (.4x818x566)
(1)
SCREW PFH
8x1 1/8
(4)
SCREW PWH
8
x5/8
(4)
SCREW PFH 8x1 1/8
(4 PLCS)
SCREW PWH 8x5/8
(4 PLCS)
BACK VIEW
AWNING
AWNING
AWNING
O4
M7
O4 BOARD IS
FLUSHED WITH
THE TOP OF
M7 BOARD.
O4 BOARD IS
CENTERED ON
M7 BOARD.
