Backyard Discovery BEACH FRONT - Page 49

STEP 18
LAG SCREW
WH 5/16x1 1/2
(4)
WASHER
L
OCK EXT
8x19
(4)
T-NUT 5/16
(2)
M11
M10
M10 - WALL RAIL - W4L06942
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
M11 - ARCHED WALL RAIL - W4L06943
5/8"x3 3/8"x43 1/4" (16x86x1097)
(1)
T-NUT 5/16
(2 PLCS)
LAG SCREW WH 5/16x1 1/2
(4 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
CENTER T-NUTS
SHOULD BE
PLACED BEFORE
MOUNTING M10
BOARD.
