Backyard Discovery BEACH FRONT - Page 50

STEP 19
BOLT WH
5/16x1 1/2
(1)
WASHER
LOCK EXT
8x19
(1)
T-NUT 5/16
(1)
NUT BARREL
WH 5/16x7/8
(1)
WASHER
LOCK EXT
12x19
(1)
BOLT WH
5
/16x1/2
(1)
J8
J8 - WALL BOARD - W4L06947
1
"x2 3/8"x25" (24x60x634)
(1)
BOLT WH 5/16x1 1/2
WASHER LOCK EXT 8x19
T-NUT 5/16
BOLT WH 5/16x1/2
WASHER LOCK EXT 12x19
NUT BARREL WH 5/16x7/8
L BRACKET BLUE 2.5x38x50x55
- L BRACKET BLUE 2.5x38x50x55 - A4M00584
(1)
LAG SCREW WH 1/4x1-1/2
LAG SCREW
W
H 1/4x1-1/2
(1)
NOTE CENTER HOLES
ON J8 BOARD LOCATED
CLOSER TO THE DECK.
