STEP 21
1 13/16"
3 1/16"
TYP SPACING
O2
SCREW PFH
8
x1 1/8
(14)
SCREW PFH 8x1 1/8
(14 PLCS)
O2 - PICKET - W4L06944
5
/8"x1 3/8"x18 1/4" (16x34x465)
(7)
