STEP 22
SCREW PFH
8x1 1/8
(18)
O2 - PICKET - W4L06944
5/8"x1 3/8"x18 1/4" (16x34x465)
(9)
SCREW PFH 8x1 1/8
(18 PLCS)
2 13/16"
TYP SPACING
1 13/16"
O2
