Parts Identification
Wood Components
(NOT TO SCALE)
H9 - HORIZONTAL TARP SUPPORT - W103818
1"x3 3/8"x54 3/4" (24x86x1392)
(1)
H73 - ROCK WALL RAIL - W100024
2
4"x86"x1238" (24x86x1238)
(2)
H79 - END SUPPORT - W100992
1"x3 1/2"x42" (24x86x1072)
(1)
H80 - GROUND BOARD - W100990
1"x3 3/8"x87 3/8" (24x86x2218)
(1)
K1 - GROUND BOARD - W103803
5/8"x5 1/4"x30" (16x134x762)
(2)
K2 - ARCH BOARD - W103812
5/8"x5 1/4"x30" (16x134x762)
(2)
K3 - GROUND BOARD - W103801
5
/8"x5 1/4"x30 3/4" (16x134x780)
(1)
K4 - WALL RAIL - W103810
5/8"x5 1/4"x30 3/4" (16x134x780)
(1)
K5 - WINDOW ARCH BOARD - W103811
5/8"x5 1/4"x30 3/4" (16x134x780)
(1)
K6 - DECORATIVE WALL BOARD - W103829
5/8"x5 1/4"x30 3/4" (16x134x780)
(1)
K7 - LEMONADE SHELF - W103825
5/8"x5 1/4"x27 7/8" (16x134x708)
(1)
K8 - GROUND BOARD - W103802
5
/8"x5 1/4"x81 3/4" (16x134x2076)
(1)
M1 - WALL BOARD - W103827
5/8"x3 3/8"x13" (16x86x330)
(5)
H10 - SHELF SUPPORT - W103961
1
"x3 3/8"x3 3/8" (24x86x86)
(2)
