High Temperature Sensors
1. Route a cable from the sensor to a Badger Meter ow monitor/transmitter. The cable can be extended up to 2000 feet,
using 2-conductor shielded 20 AWG or larger stranded copper wire. Be sure to leave enough exibility in the cable or
conduit to allow for future service of sensor, if necessary.
2. Connect to the cable inside the sensor electronic housing on the Series 220 sensors, or attach to the sensor cable on the
Series 225/226 and connect with standard wire nuts.
3. When connecting to a Badger Meter ow monitor or transmitter, locate the section of terminal strip on the monitor
labeled SENSOR INPUT or SENSOR. Connect the red (or white) wire to IN, SIGNAL(+) or SIGNAL terminal, connect the
black wire to GND, SIGNAL(-) or COM terminal, and connect the shield drain wire (if applicable) to SLD.
OTE:N When interfacing with other equipment, the signal wave forms and power requirements are as described in
"Specifications" on page 18.
ELECTRICAL INSTALLATION SAFETY
The Series 200 sensor is approved, as an entity, as intrinsically safe when installed in conformance with Badger Meter
installation drawing 06-480-002 (Figure 5) as specified on the blue label identifying an intrinsically safe sensor.
Entity approval implies that only the sensor is approved as intrinsically safe. Unless power supplies, equipment, and
instruments connected to the sensor are each rated either explosion-proof or intrinsically safe, these devices cannot be
installed in a hazardous area. The referenced installation drawing shows such apparatus located in a non-hazardous location.
Proper interfacing between the hazardous and non-hazardous areas must be provided. It is of absolute importance that
this interface be constructed and that all wiring be performed by qualified contractors. To protect the intrinsic safety of the
installation, the connection of the intrinsically safe sensor to instruments and or power supplies must take place using an
approved intrinsically safe barrier located in a non-hazardous area. These barriers, listed below, are readily available from
various suppliers.
Manufacturer Barrier
Crouse-Hinds Spec 504 Cat No. SB19140M0715
Measurement Technology Ltd. MTL 715+ 15V
R Stahl Intrinspak 9001/1-158-150-10
Electrical Installation Safety
Page 11 February 2018 SEN-UM-01635-EN-11
