Badger Meter 220 Series User Manual

SPECIFICATIONS
Sensor Sleeve and Hex Adapter for 220BR
Sleeve: Admiralty brass, UNS C44300
Hex adapter: Lead-free brass, C89833
Sensor Sleeve and Hex Adapter for
225BR, and 226BR
Sleeve: Admiralty brass, UNS C44300
Hex adapter: Lead-free brass, C89833
Sensor Sleeve and Hex Adapter for 220SS
and 226SS
Series 300 stainless steel
Sensor Sleeve and Mounting Adapter for
220PV
Polyvinyl chloride (PVC)
Temperature Ratings for 220BR, 220SS
Standard version: 221 F (105 C) continuous service
High temperature version: 285° F (140.6° C) continuous service; 305° F (150° C) peak
temperature (limited duration)
Temperature Ratings
220SS 180° F (82° C)
220BR 180° F (82° C)
220PV 140° F (60° C)
225BR 180° F (82° C)
226BR 180° F (82° C)
226SS 180° F (82° C)
Pressure Ratings
At 100° F At 300° F
220SS 400 psi 325 psi
220BR 400 psi 325 psi
225BR 300 psi 210 psi
226BR 400 psi 250 psi
226SS 400 psi 300 psi
220PV 100 psi @ 68° F
Recommended Design Flow Range 0.5…30 ft/sec Initial detection below 0.3 ft/sec
Accuracy ± 1.0% of full scale over recommended design flow range
Repeatability ± 0.3% of full scale over recommended design flow range
Linearity ± 0.2% of full scale over recommended design flow range
Transducer Excitation
Supply voltage = 8V DC min. 35V DC max.
Quiescent current = 600 uA (typical)
OFF State (V
High
) = Supply voltage – (600 uA
*
Supply impedance)
ON State (V
Low
) = 1.2V DC @ 40 mA (15 Ω + 0.7V DC)
Output Frequency 3.2…200 Hz
Output Pulse Width 5 msec ±25%
Electrical Cable for Standard Sensor
Electronics
20 feet of 2-conductor 20 AWG shielded UL type PTLC wire provided for connection to
display or analog transmitter unit. Rated to 221° F (105° C). May be extended to a maximum
of 2000 feet with similar cable and insulation appropriate for application.
Electrical Cable for IR Sensor Electronics
48 inches of UL Style 116666 copper solid AWG 18 wire with direct burial insulation.
Rated to 221° F (105° C).
Certifications CE certified
Specications
Page 18 February 2018SEN-UM-01635-EN-11
