BaehrTec A2000 operating instructions
English – V101 - effective 10/13
4.1.6 Rear view
Fig. 9
When working from the case, we recommend removing the storage
tray from the case in order that the heat created by the device can
escape from the case and to avoid potential head build-up.
(43) Filter cassette
(44) Knurled screws
(45) Fuse clip
For microfuses 2x 3.15 A delay (type H)
(46) Power connector
Only connect the connection cable provided or one approved by the manufacturer.
(47a) Nameplate
(47b) Serial no. plate
(48) Connector socket for foot pedal
