6 Technical specifications
BaehrTec A2000
Medical device
Class 2A in accordance with EC Directive 93/42
Medical devices
EMC test
Under EN 60601-1
Operating voltage
110 – 240 V AC voltage
Frequency
50 – 60 Hz
Micromotor speed range
6,000 – 40,000 rpm adjustable
Accuracy of the speeds
6,000 – 10,000 rpm, tolerance +/- 20 %
10,000 – 40,000 rpm, tolerance +/- 10 %
Power consumption
Max. 150 W
Micromotor voltage
24 V
Working voltage
28 V
Controller dimensions (W x D x H) in mm
(without handpiece outlet, without handpiece
holder and without filter cassette)
220 x 195 x 110
Controller weight
Approx. 2,100 g
Handpiece dimensions (W x min. diameter x max.
diameter) in mm
~117 x ~19 x ~24
Handpiece weight
Approx. 99 g
Dust bag lid weight
Approx. 70 g
Ambient temperature (operation)
+10° - +35° C
Storage temperature
-5° - +40°C
Humidity
30% - 85 %
Permitted air pressure
800 hPa - 1060 hPa
Max. vacuum (suction level 1) with filter and
dust bag
- 35 m/bar +/- 10%
Max. vacuum (suction level 1+) with filter and
dust bag
- 40 m/bar +/- 10%
Max. vacuum (suction level 2) with filter and
dust bag
- 55 m/bar +/- 10%
Max. vacuum (suction level 2+) with filter and
dust bag
- 62 m/bar +/- 10%
Max. vacuum (suction level 3) with filter and
dust bag
- 67 m/bar +/- 10%
Max. vacuum (suction level 3+) with filter and
dust bag
- 75 m/bar +/- 10%
Max. vacuum (suction level 4) with filter and
dust bag
- 80 m/bar +/- 10%
Max. vacuum (suction level 4+) with filter and
dust bag
- 85 m/bar +/- 10%
Max. vacuum (suction level 5) with filter and
dust bag
- 90 m/bar +/- 10%
Max. vacuum (suction level 5+) with filter and
dust bag
- 97 m/bar +/- 10%
Max. vacuum (suction level 6) with filter and
dust bag
- 105 m/bar +/- 10%
Fuse
2x microfuse, 3.15 A delay (Type H)
IP Protection Class 30
Not protected against water
Protection against penetration from solid
foreign bodies with a diameter of > 2.5 mm
Volume
Measurement conditions:
Device from the front; distance 1m; dust bag
inserted; turbine protection filter inserted;
filter cassette mounted, handpiece relocated 1m
from the controller and covered with hood.
Extracted air flows freely, not discharging in the
direction of the sound-level measurement device.
Handpiece speed:
6,000 rpm
48 db to 55 db +/- 10%
Subject to visual and technical changes.
