INTRODUCTION

REFERENCE DOCUMENTS

WBPEEUI240756A0 1 - 5

REFERENCE DOCUMENTS

Table 1-2 lists Elsag Bailey instructions referenced in this

instruction.

MFC Multifunction controller module. A multiple loop controller with data acquisition and

information processing capabilities.

MFP multifunction processor module. A multiple loop controller with data acquisition and

information processing capabilities.

MMU Module mounting unit. A card cage that provides electrical and communication

support for INFI 90 OPEN/Network 90 modules.

OIS Operator interface station. Integrated operator console with data acquisition and

reporting capabilities. It provides a digital access into the process for flexible control

and monitoring.

Smart transmitter A field measuring device that uses digital communication to transmit information.

TM Termination module; provides input/output connection between plant equipment and

the INFI 90 OPEN/Network 90 modules.

TU Termination unit; provides input/output connection between plant equipment and the

INFI 90 OPEN/Network 90 modules.

Table 1-1. Glossary of Terms and Abbreviations

(continued)

Term Definition

Table 1-2. Reference Documents

Number Title

I-E21-56 SmartLink Transmitter Management Software

I-E92-501-2 Configuration and Tuning Terminal, Type CTT02

I-E96-192-1 Operation manual, Operator Interface Station (40 Series)

IIOIS42

I-E96-200 Function Code Application Manual

I-E96-201 IMMFP01 Multifunction Processor

I-E96-202 IMMFP02 Multifunction Processor

I-E96-203 IMMFP03/03B Multifunction Processor

I-E96-211 IMMFC03 Multifunction Controller

I-E96-212 IMMFC04 Multifunction Controller

I-E96-213 IMMFC05 Multifunction Controller

I-E96-416 NTAI05 Analog Input Termination Unit

I-E96-432 NTFB01 Field Bus Termination Unit

I-E96-436 NIAI04 Analog Input Termination Module

P-E21-001 Installing a 4 to 20 mA Transmitter in a Hazardous Location

WBPEEUI110501A0 Smart Transmitter Terminal, Type STT03

WBPEEUI200501A0 Module Mounting Unit (IEMMU11/12/21/22)

WBPEEUI220756A0 Operation manual, Operator Interface Station (40 Series)

IIOIS43
