TROUBLESHOOTING
MODULE STATUS REPORTS
5 - 2 WBPEEUI240756A0
®
Transmitter Status Reports (IMFEC11 ONLY)
The IMFEC11 module continuously monitors smart transmit-
ters to provide status reports. The module sends transmitter
status data to the controlling module (MFP/MFC). Access this
data from the controlling module by viewing the module sum-
mary display on the operator interface.
From the module summary display, call up the I/O SLAVE sta-
tus report. When the function block listed (within the I/O
SLAVE status report) contains a smart transmitter definition
function code, that status report applies to a smart transmitter
connected to an IMFEC11 module. The status report will dis-
play specific smart transmitter error codes when an error
occurs. The status report lists the following:
I/O SLAVE ERROR NUMBER (#), SLAVE ADDRESS (#),
BLOCK NUM. (#)
Table 5-2 lists smart transmitter error codes and their mean-
ing. For corrective action, refer to the product instruction for
the smart transmitter in error.
A communication failure will occur if a configuration download
is attempted to a transmitter whose configuration lockout
jumper is set to the lockout position. Each smart transmitter
has its own function block. If a smart transmitter communica-
tion failure occurs, its function block appears in the I/O SLAVE
report listing.
NOTE:
The configuration lockout jumper (on the transmitter) pre-
vents the transmitter from being configured. Transmitter configura-
tion and operation can be monitored, but the transmitter
configuration cannot be changed from any source. Refer to the
smart transmitter product instruction for information about using the
lockout feature.
Table 5-2. Smart Transmitter Error Codes
Error No. Description
6 Not responding
7 Configuration mismatch
8 Wrong transmitter type
9 Input failure or memory failure
10 Overpressured
11 Temperature range exceeded
12 Output fixed
13 Calibration required
14 Transmitter being calibrated
15 Transmitter off-line
16 Communication error
