NTAI05 TERMINATION UNIT CONFIGURATION
CONFIGURING INPUTS
A - 2 WBPEEUI240756A0
®
Table A-1. NTAI05 Dipshunt Settings
Application/
Signal Type
Dipshunt
Configuration
Dipshunt
Locations
Connecting
Cable
System powered
4to20 mA
XU1 to
XU15
1
NKTU01
Externally powered
4to20 mA
Single-ended voltage
2
Differential voltage
2
Above applications:
4 to 20 mA
1 to 5 VDC
0 to 1 VDC
0 to 5 VDC
0 to 10 VDC
-10 to +10 VDC
XU17
NOTES:
1. XU16 is not used.
2. FSK not supported at this time.
12345678
16 15 14 13 12 11 10 9
12345678
16 15 14 13 12 11 10 9
12345678
16 15 14 13 12 11 10 9
12345678
16 15 14 13 12 11 10 9
12345678
16 15 14 13 12 11 10 9
TP25171C
Figure A-2. NTAI05 Cable Connections
T00922A
IMFEC1

NKTU01
P1
P1
P3
P2
NTA105
