SPECIFICATIONS
1 - 8 WBPEEUI240756A0
®
Electromagnetic Compatibility
Conducted transients
Communication baud rate
9600 baud
Environmental
Ambient temperature 0° to 55°C (0° to 131°F) (noncondensing)
Relative humidity 5% to 95% up to 55°C (131°F)
5% to 45% at 70°C (158°F) (noncondensing)
Atmospheric pressure Sea level to 3 km (1.86 mi)
Air quality Noncorrosive
Mounting
Occupies a single slot in a standard INFI 90 OPEN module mounting
unit (MMU)
CE mark
EMC96 Directive 89/336/EEC
Low Voltage Directive 73/23
/EEC
This product, when installed in an INFI 90 OPEN cabinet, complies with
the following Directives/Standards for CE marking.
EN50082-2 Generic Immunity Standard - Part 2: Industrial Environment
EN50081-2 Generic Emission Standard - Part 2: Industrial Environment
EN61010-1 Safety Requirements for Electrical Equipment for Measure-
ment, Control and Laboratory Use - Part 1: General Requirements
Certification
Canadian Standards Association
(CSA)
Factory Mutual (FM) (pending)
Certified for use as process control equipment in an ordinary
(nonhazardous) location
Approval for the following categories, nonincendive for:
Class I Division 2, Groups A,B,C,D
Class II, Division 2, Groups F,G
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Table 1-5. Specifications
(continued)
Property Characteristic/Value
Test Common Mode
Normal
Mode
Pulse voltage test (1.2/50 µS)
(IEC 801-5)
2 kVp 1 kVp
Line frequency wave (50 Hz) 50 Vp N/A
Low voltage wave train
(Sweep from 10 KHz to 1 MHz)
50 Vp N/A
Damped 1 MHz oscillatory wave
(IEC 1000-4-12)
1 kVp 0.5 kVp
Electrical fast transient/burst
(IEC 801-4)
1 kVp N/A
Conducted RF interferences
(IEC 801-6 level 3)
10 V RMS N/A
Keep cabinet doors closed. Do not use communication equipment closer than 2 m
(6 ft.) from the cabinet.
