WBPEEUI240756A0
Preface
The IMFEC1M Analog Input Module module supplies 15 field
inputs to the INFI 90
®
OPEN strategic process management
system. There are two variations available.
The IMFEC12 module interfaces to conventional transmitters
and standard analog inputs. It links process data and commu-
nication from field devices to all multifunction processors
(MFP), or the IMMFC03, IMMFC04 and IMMFC05 multifunc-
tion controller (MFC) modules. The IMFEC12 module can be
used as a direct replacement for the IMASI02 module; however,
baseband communications are not supported.
The IMFEC11 module performs all the functions of the
IMFEC12 module plus it is an interface for Bailey-Fischer &
Porter smart transmitters and other smart devices. It links pro-
cess data and communication from Bailey-Fischer & Porter
smart devices to all multifunction processors (MFP), or the
IMMFC03, IMMFC04 and IMMFC05 multifunction controller
(MFC) modules. The analog input module operates in one of
two modes: FSK field bus mode (FSK digital data and commu-
nication) and FSK analog point-to-point mode (analog inputs
with or without FSK digital communication available). The
IMFEC11 module can be used as a direct replacement for the
IMFBS01 Field Bus Module; however, baseband communica-
tions are not supported.
This instruction explains the FEC features, specifications and
operation. It explains how to set up and install the FEC mod-
ule, and covers troubleshooting procedures.
The system engineer or technician using the FEC module
should read and understand this instruction before installing
and operating the module. In addition, a complete understand-
ing of the INFI 90 OPEN system is beneficial.
