xvii. Finally,iftheroadwheelshavebeen
removed, re-tighten using a calibrated
torquewrenchto130Nm(onallM12wheel
bolts-insequence,i.e.North,South,East,
Westnot clock or anticlockwise.) DONOT
overtightenthisisjustasdangerousasto
under-tighten,asthiscandistortthewheel
rims.Avoidtheuseofpowerwrenches.
!
Thetorquesettingsshouldbe
re-checkedafter50km/30miles.
Wheelboltsshouldneverbe
lubricated.
InordertooperatetheAL-KObraking
systemcorrectlyadequatetractionof
caravan wheels is required when
reversing.Thereforesurfaceconditions
thatwouldresultinalack oftraction
should be avoided, for example: pea
shingle/loosegravel.
Careshouldbetakenwhentraversing
rampsorotherobstaclesinorderto
preventdamagetothecaravanunder
gear.Whenapproachingsuch
obstaclesreducetowingspeed
appropriately.
Chassis Lubrication Points
1. Grease the drawbar in the area of the
bellows.
2.Greasethebearingbushthroughthegrease
nipplesonthehousingandthecartridge.
3.Grease the pivot bolt of theoverrunlever
and handbrake levers through the grease
nipple.
4.Greasethejointofthebrakerodandtting.
5.Oil the joints of the spring cylinder in the
handbrakelever.
Lubricant type: Multi-purpose grease to DIN
51825KTA3K4.
AL-KO ATC Trailer Control System
AL-KO ATC is an electronic, emergency
control system for caravans and trailers.  It
automatically recognises critical swinging
motions and applies the caravan brakes
accordingly to regain control of the caravan
andcar.
SafetyInformation
AL-KOATCisapassivesafetyproduct
thatactivatesthebrakingsystem
onthecaravaninunsafedriving
conditions.
The driver has a responsibility under law to
ensurethattheelementsoftowingsafetyare
met, including driving within the legal speed
limit,considerationofroad,weatherandother
trafc conditions, and correct loading and
couplingofthecaravan.
Theelectricalconnectionbetweenthetowing
vehicle and the caravan must be in good
workingorder.
Operating Instructions
After coupling the caravan correctly to the
towingvehicle,connectthe13pinplugtothe
towbar.
Uponconnection,ATCwillcarryoutaninitial
selftestandtheLEDlightonthefrontfairing
willlightuponRED.Duringtheselftest,the
