Bailey Pegasus GT65 - Battery Box Connections and Solar Input

48
THEELECTRICALSYSTEM
!
Switchoffallappliancesbefore
disconnectingthebattery.
Negativeconnectionsshouldalways
bedisconnectedrstandreconnected
last.
Cartypebatterychargersarenot
suitableforchargingaleisurebattery
andmaydamageit.
Whennotusingthecaravanalways
ensurethatthefridgecontrolknobis
turnedtothe“off”position.Failureto
dothiswillresultinaatbatterydue
to12vpowerdrainfromthefridge
circuitrelays.
Battery Box Connections
ThePegasus GT65 rangeis ttedwith a 12v
external solar panel connection point.  This
can be found under the caravan mains inlet
insidethebatterybox.
TheUnicornrangealsofeaturesaconnection
forafreestandingexternalsatellitedish.This
connectionisalsolocatedionthesideofthe
vehiclealongwiththeexternal230vsocket.
