Bailey Pegasus GT65 - On-board Tank Filling; Internal Water Supply

37
THEWATERSYSTEM
Removingtheplug:
•Switch off the 12v supply at the main
controlpanel(pumpisolatorswitch)
•Pull the plug out of the socket using the
handgrip
•Shutthelid
•Donotrunthepumpwithoutwater
•Donotusethepumpinwatertemperatures
above40°C(100°F)
•Itisbesttostandthepumpverticallyinthe
tank.
•The micro-switch or phosphor bronze
contactsinthesocketcanberemovedfor
inspectionorreplacement
•The pressure switch is sensitive to drops
in battery voltage.  As the voltage falls,
shouldtheunitneedadjustment,turnanti-
clockwise
Filling the on-board tank
•Switchoffthe12vsupplyfortheon-board
pump at the main control panel (pump
isolatorswitch)
•Locate the 2-way valve in the heater
compartment.
Turnthe2-wayvalvetotheopenposition
•Switch on the 12v supply for the external
pump at the main control panel (pump
isolatorswitch)andlltheon-boardtank
•When the water runs from the overow
pipebelowthecaravan,switchoffthe12v
supply for the externalpump at the main
controlpanel
•Return the 2-way valve in the heater
compartmenttotheclosedposition
Internal supply
•Openonecoldtap(e.g.atthekitchensink)
•Locate the 2-way valve in the heater
compartment
•Turnthe2-wayvalvetotheclosedposition
•Switchonthe12vsupplyfortheon-board
pump at the main control panel (pump
isolatorswitch)
•Waterwillowfromtheopentapexpelling
anytrappedairinafewseconds
•Turn offthetap;the systemis now ready
foruse
•Donotrunthepumpwithoutwater
