Baintech PowerTop User Operation Manual V8 11
PowerTop Technical Information
Features
 12V 100Ah Gel battery
 Top of unit made from anodised aluminium
 In-built 5A AC connected battery charger
 In-built electronics (VCR) for accepting charge from vehicle input, for voltages above 13.2V
 LCD voltmeter with LOW volt audio alarm buzzer
 DC On/Off switch to power down the unit
 Total five socket outlets
o Universal USB Socket
o Engel Socket
o LockOn Socket
o 2 x Ciga Sockets
o Protected by 20A thermal self-resettable breaker
 6 led indicators:
o FLAT BATTERY
o MAINS
o BOOST
o FLOAT
o SOLAR/EXTERNAL
o VEHICLE
 Fitted 3x 50A Anderson Connectors
o Red Solar/External (12V solar panel input can be unregulated)
o Blue Vehicle Charge Input connection
o Grey Load connection
 Protected by 50A thermal self-resettable breaker
 Can be used for regulated output from a AC charger, DC-DC charger or solar charger to
charge the battery
Specifications
Battery
100Ah 12V Gel Battery
In Built Battery Charger
5A 12V AC Charger
Vehicle input voltage for VCR
Above 13.2V
Volt Meter Alarm Level
11V
Socket Protection
20A Self-resettable Breaker
Grey Anderson plug (output) protection
50A Self-resettable breaker
USB Socket Output
5V 2.3A
Maximum Load across all sockets
200W
Dimensions (L x W x H)
330 x 175 x 275 mm
Weight
32kg
Warranty
12 months
 After warranty period service is available.
 Opening unit voids warranty.
 For standard warranty terms please visit http://www.baintech.com.au/warranty .
 Replacement battery available, please contact Bainbridge Technologies.
