Baintech PowerTop User Operation Manual V8 12
DO’s and DON’Ts
DO’s:
1. Disconnect all the loads and remove the connections to Blue and Red Anderson connectors while
using the AC internal charger.
2. Maximum recommended DC-DC charger is 20A.
3. Solar charging - regulated charging through Grey Anderson plug and unregulated charging through
Red Anderson plug. DC ON/ OFF switch must be ON while charging from Solar.
4. Please follow the ratings and connections for Solar charging as mentioned in page 7.
DON’Ts:
1. DON’T connect any load while charging through internal AC charger, it is only 6.6A charger.
2. DON’T use high capacity DC-DC charger beyond the recommended charging current (max 20A).
3. DON’T go beyond the recommended load for each socket as mentioned in page 10.
4. DON’T open the unit, it will void the warranty.
