Baintech PowerTop User Operation Manual V8 5
Charging
IMPORTANT NOTE: DC On/Off Switch must be ON for charging (see page 3 for switch location).
Internal AC Charger
The PowerTop comes with an internal 6.6A AC charger.
The charger operates when the AC plug is connected
into the unit. When charging with the AC charger,
disconnect all loads and remove the connections to the
Blue and Red Anderson connectors. Disconnect the
power to the AC charger after 24 hours, as the battery
will be fully charged.
MAINS LED Operation
When AC power is connected and powering the internal AC charger the MAINS LED will turn on.
The MAINS LED will turn off when the internal charger output turns off, which will occur when the
AC power is disconnected.
Fast Charging
IMPORTANT NOTE: DC On/Off Switch must be ON for charging (see page 3 for switch location).
If you require faster charging we recommend using a 20A (maximum) charger suited for Gel batteries with the
following voltage set points:
Bulk 14.2V
Float 13.7V
The external charger is to be connected to the Grey Anderson connector labelled 50A Battery Output.
