Baintech PowerTop User Operation Manual V8 8
Regulated Solar DC Charging
IMPORTANT NOTE: DC On/Off Switch must be ON for charging (see page 3 for switch location).
If the solar panel is supplied with a solar charge controller or you have an external solar charge controller they must
meet the following requirements:
20A maximum charge current
Bulk 14.2V
Float 13.7V
If the solar charger controller meets these requirements connect the device to the Grey Anderson connector labelled
50A Battery Output.
Vehicle Charging
IMPORTANT NOTE: DC On/Off Switch must be ON for charging (see page 3 for switch location).
If you want to charge the PowerTop from the vehicle alternator, connect a cable to the starter battery, connect the
other end of the cable to the Blue Anderson Plug on the PowerTop labelled Vehicle charge input. Fuse the cable at
the start battery end of the cable. The vehicle voltage must be above 13.2V to charge the PowerTop battery.
