FRONT HYDRAULIC DISK BRAKE INSPECTION
REAR HYDRAULIC DISK BRAKE INSPECTION
Rear disk brake
caliper
Brake hose
Sight gauge
Brake uid
reservoir
Brake uid cap
Brake uid level
Brake uid cap
Brake hose
Front disk brake caliper
Lower mark
Brake uid reservoir
MAINTENANCE
1- Inspect the front disk brake caliper for leakage. If brake uid leaks, the
safety of riding could be affected.
2- Inspect the brake hose for cracks, and the joint for leakage.
3- Check the brake uid level in the brake uid reservoir, if level is at or below
the LOWER mark, inspect brake pads for wear and hydraulic system for leaks.
4- To add brake uid, unscrew the 2 screws on top of the brake uid container.
Add DOT3 or DOT4 brake uid. Do not mix brake uid types.
1- Inspect the rear disk brake caliper for leakage. If brake uid leaks, the
safety of riding could be affected.
2- Inspect the brake hose for cracks, and the joint for leakage.
3- Check the brake uid level in the brake uid reservoir, if level is at or
below the middle of sight window inspect brake pads for wear and hydraulic
system for leaks.
4- To add brake uid, unscrew cap on top of brake uid container. Add
DOT3 or DOT4 brake uid. Do not mix brake uid types.
