6
SPECIFICATION 70CC 110CC
Wheel Base 41.34 in. (1050mm) 41.73 in. (1060mm)
Seat Height 24.02 in. (610mm) 25.2 in. (640mm)
Grips Height 39.17 in. (995mm) 41.73 in. (1060mm)
Ground Clearance 5.51 in. (140mm) 7.09 in. (180mm)
Assembled Weight 130 lbs. (59kg) 137 lbs. (62.14kg)
In Box Weight 174 lbs. (79kg) 185 lbs. (84kg)
Passenger Capacity Operator only Operator only
Maximum Weight 165lbs. (75kg) 165lbs. (75kg)
Cargo Capacity No Cargo No Cargo
Gears 4 + Neutral 4 + Neutral
Clutch Manual Manual
Final Drive Frt 420-14T / Rr 420-42T Frt 420-14T / Rr 420-42T
Engine Type 4 stroke aircooled 4 stroke aircooled
Displacement 72cc 107cc
Bore & Stroke 1.85 X 1.63 inch
(47mm x 41.4mm)
2.06 X 1.93 inch
(52.4mm x 49.5mm)
Compression Ratio 8.8:1 9.8:1
Power (HP) 5.10 hp 6.97 hp
Valve Train OHV: Two valve OHV: Two valve
Top Speed (MPH) 46 mph (74 kph) 50 mph (80.5 kph)
Dimensions / Measurements / Weight
Capacities
Transmission
Engine Specications
SPECIFICATIONS
